FEATURES

Simple Operation

NSA & DOD Approved

Listed on Degausser Approved Products List

Chamber-Type Degausser

Pulse Discharge Magnetic Field

One-Pass Operation

Continuous Duty

38 Second Cycle Time

Throughput 270 hard drives/hr, 900 tapes/hr

PERFORMANCE

Erasure :Independent scientific testing confirms this degausser erases longitudinal and perpendicular disk storage devices with a Coercivity of 5000 Oersteds and tape media with a Coercivity of 2800 Oersteds.

Media Size :The HD-1T accommodates hard drives up to 1 inch high by 4 inches wide by 5.8 inches deep including floppy disks, zip disks, and hard disk drives without disassembly. The HD-1T accommodates tape media up to 1 inch high by 4.3 inches wide by 7.3 inches deep including DLT, LTO, 8mm, DDS, and VHS. The HD-1T can accommodate multiple tapes per cycle.

CONTROLS AND INDICATORS

Illuminated POWER Switch

START Push-Button

NORMAL and FAULT Indicators – Backlit 48-character digital display prompts normal operation, simple user-activated self-calibration function, and comprehensive service and diagnostic functions. Process evaluation feature allows operator to obtain preventative maintenance when indicated.

POWER REQUIREMENTS

120 or 230 V, 50/60 Hz

PHYSICAL ENVIRONMENT

Temperature – Operation from 0°C (32°F) to 50°C (122°F)

Relative Humidity – 5% to 95%, noncondensing

Vibration and Shock – Designed to withstand commercial shipping and handling conditions

Altitude – Operation to 10,000 ft (3,000 m)

DIMENSIONS

Width – 30 in (76.2 cm)

Height – 54.8 in (139.2 cm)

Depth – 28.5 in (72.4 cm)

Weight – 420 lb (191 kg)
